Series 4060 Safety valve made of stainless steel, angle-type

Product informationWith the 451r series with the KUB-Clean bursting disc in combination, Goetze ensures the comprehensive protection of systems. During routine operation this device prevents the smallest amounts of biological agents being released by safety valves which may leak.Combined with the requirements of Hygienic Design and CIP/SIP capability, the bursting disc in combination with the safety valve also prevents the safety valve seal from being able to can prevent the safety valve seat seal from being able to “stick” due to contact with the medium.connection typesClamp connectionsMore information please go link: 451r with bursting disc

Product information The 4100 series is characterised by its compact design and offers the advantage that the inlet and outlet openings are identical, which can significantly reduce installation costs. The availability up to a nominal diameter of DN100 allows flexible adaptation to different system requirements.A key feature of the 4100 series is the flow-optimised shaped diaphragm. Compared to conventional sealing solutions, this innovative cone-shaped diaphragm technology enables optimum separation of the wetted area from the spring chamber of the valve.The design of the safety valve minimises dead space and ensures excellent cleanability and hygiene. Such properties are essential for use in the pharmaceutical, food and beverage industries, where strict hygiene standards apply.In terms of certifications and approvals, the 4100 series has a specific approval for liquids only and another for use with gases and liquids. An ASME approval is also provided, which emphasises conformity with international industry standards.The hygienic design, the variety of connections, the ease of maintenance and the short delivery times of the valve round off the profile of the 4100 series and make it an ideal solution for demanding applications in beverage production and related industries.connection typesClamp connectionsCone socketThreaded ferrule connectionAseptic grooved clamp connectionsAseptic collar clamp connectionAseptic-Threaded ferrule connectionaseptic collar connectionaseptic collar flange connectionAseptic grooved flange connectionButt weldsContainer flangeMore information please go link: 4100

Product informationGOETZE diaphragm valves – straight-through valves for precise processesThe diaphragm valve with straight-through valve body from GOETZE is the ideal solution for hygienically sensitive applications in the pharmaceutical, food and beverage industries, as well as in biopharmaceuticals, cosmetics and medical technology.Thanks to its compact design and modular system, the valve can be individually configured and optimally integrated into existing systems. Features & BenefitsEmptying without defined angle of rotation thanks to optimally positioned connectionsCIP/SIP-compatible – no need to retighten screws after steam sterilisationHigh process reliability thanks to defined, reproducible membrane compressionLow maintenance & durable: no loose parts, no wear limitation requiredEasy operation: closing and stroke limitation can be adjusted without dismantlingCompact stainless steel drive in 6 and 10 bar versionsEccentric connections simplify system installationFuture-proof thanks to modular valve system with a wide range of adaptation optionsWith the GOETZE straight-through diaphragm valve, you can rely on maximum flexibility, process reliability and efficiency in any production environment.connection types Flange connectionWeld endClampMilk pipeMore information please go link: GOETZE diaphragm valve – straight-through valve for hygienic processes

Product informationGOETZE diaphragm valves – T-valve for flexible system integrationThe diaphragm valve with T valve body from GOETZE offers maximum adaptability for complex piping and process structures. It is the perfect choice for industries such as pharmaceuticals, food, beverages, biopharmaceuticals, cosmetics and medical technology.The T-design allows for flexible flow paths and combines hygienic safety with a compact design. Features & BenefitsEmptying with vertical valve seat – regardless of the angle of rotationSterilisation-proof: CIP/SIP-compatible without retightening the screwsHigh process reliability thanks to defined and reproducible sealingLow maintenance & durable: no loose parts, no readjustment requiredUser-friendly: closing and stroke limitation can be adjusted without dismantlingCompact stainless steel actuator for 6 and 10 barEasy system integration thanks to eccentric connectionsModular and expandable: integrated valve system with accessories and optionsWith the GOETZE diaphragm valve in T-design, you benefit from flexible system planning, hygienic safety and reliable performance.connection types Flange connectionWeld endClampMilk pipeMore information please go link: GOETZE diaphragm valve – T-valve for flexible system integration

Product informationGOETZE Diaphragm valves – tank bottom valves for hygienic tank bottom valve processesThe diaphragm valve with tank bottom valve body from GOETZE has been specially developed for integration into tanks and containers. Whether in the pharmaceutical industry, food and beverage production, biopharmaceuticals, cosmetics or medical technology – it guarantees hygienic processes of the highest standard.The container design ensures optimum process control directly at the tank and enables reliable, efficient emptying.Features & advantagesEmptying thanks to optimally aligned connections, regardless of the angle of rotationNo reworking after sterilisation: CIP/SIP-compatible without screw retighteningProcess reliability thanks to defined and reproducible diaphragm compressionLow maintenance: no loose parts, no wear or readjustment requiredEasy operation: closing and stroke limitation adjustable without dismantlingCompact stainless steel actuator for 6 and 10 barEfficient integration into container systems thanks to eccentric connectionsFlexibly expandable thanks to modular valve system and accessoriesWith the GOETZE diaphragm valve in tank design, you can be sure of maximum hygiene, easy handling and reliable results in sensitive tank processes.connection types Flange connectionWeld endClampMilk pipeMore information please go link: GOETZE diaphragm valve – Tank bottom valve for tank and container processes

Product informationThe 9641 backflow preventer is the robust stainless steel version designed for connection to standpipes and demanding applications.It reliably protects drinking water systems in accordance with DIN EN 1717 up to fluid category 4 and is particularly suitable for construction water supply, food processing plants or cleaning processes.The proven BA principle with three pressure zones ensures maximum safety, whilst the stainless steel design meets the highest standards of hygiene and corrosion resistance.The combination of efficiency, durability and compact design makes the 9641 the ideal solution for demanding applications.connection typesInternal pipe threadMale threadMore information please go link: Backflow preventer 9641 DN20 stainless steel for standpipe | GOETZE
