    Quartz™ explosionproof on/off valve monitor

    Liên hệ
    QUARTZ
    Quartz
    Neles
    Còn hàng

    The Quartz discrete valve monitor is available in explosionproof (QX), nonincendive and intrinsically safe (QN), low temperature (QC) and general purpose (QG) versions. The robust epoxy coated aluminum enclosure is extremely durable and well suited for use in corrosive, heavy wash-down environments. A broad range of switches, position transmitters and communication options are available to accommodate most applications.

    Đặt hàng
    So sánh
    Yêu thích
    • Chia sẻ qua viber bài: Quartz™ explosionproof on/off valve monitor
    • Chia sẻ qua reddit bài:Quartz™ explosionproof on/off valve monitor

    Quartz™ explosionproof on/off valve monitor

    Highly reliable discrete valve monitor

    The Quartz discrete valve monitor is available in explosionproof (QX), nonincendive and intrinsically safe (QN), low temperature (QC) and general purpose (QG) versions. The robust epoxy coated aluminum enclosure is extremely durable and well suited for use in corrosive, heavy wash-down environments. A broad range of switches, position transmitters and communication options are available to accommodate most applications.

    Features

    • Wide variety of switching & communication options including solid state proximity and mechanical switches as well as communication and 4-20mA continuous outputs.
    • Enclosures optimized for tough process environments
    • Rapid enclosure access
    • Quick set cams
    • Extremely compact with space saving visual indication
    • Dual shaft o-ring seals
    • The oil impregnated bronze bushing maintains smooth operation and eliminates the potential for shaft seizure due to actuator shaft eccentricity.
    • Top inner and bottom outer shaft o-rings seal the drive bushing from both external corrosives and internal contaminants

    Applications

    • Automated On/Off valve applications in hazardous process environments
    • Corrosive and wash down process environment
    • Food and beverage
    • Chemical process
    • Pharmaceutical and biotech
    • Agri-processing
    • Oil and gas
    • Marine and offshore



    Monitor an automated on/off valve in all process areas

    The Quartz monitors and reports valve position with visual indicator and signals to the controller.

    Specifications


    QX35 / QN35:
    Universal voltage switching and solenoid termination
    QX45 / QN45:
    Namur sensors (7-24 VDC)
    Communication options:
    AS-Interface, Foundation Fieldbus and DeviceNet
    Temperature range:
    up to -55 °C … +80 °C
    Material:
    Epoxy coated anodized aluminum, optional polycarbonate cover
    Hazardous area approvals:
    Ex d Ex i, Class I, Division 1 and Class I, Division 2 (for complete list see technical bulletin)
